bme280 breakout
Checks passedGPT-6.1 Sol · $0.61 · Oct 2, 2026
Gate L3· ERC: 0 critical· DRC: 0 critical
Download native KiCad board Public output artifacts
Generated board gallery
17 saved board previews from end-to-end public tasks. A good-looking render is not proof of a working board: each preview carries its recorded grading outcome and the native KiCad output.
esp32 wroom breakout
Checks passedGPT-6.1 Sol · $1.37 · Oct 2, 2026
Gate L3· ERC: 0 critical· DRC: 0 critical
Download native KiCad board
esp32s3 devkit
Checks passedGPT-6 Astra · $6.97 · Oct 3, 2026
Gate L3· ERC: 0 critical· DRC: 0 critical
Download native KiCad board
bme280 breakout
Checks passedGPT-6 Sol · $1.48 · Oct 15, 2026
Gate L3· ERC: 0 critical· DRC: 0 critical
Download native KiCad board
buck 24v 5v 3a
Checks failedGPT-6.1 Sol · $1.25 · Oct 2, 2026
Gate L2· ERC: 0 critical· DRC: 0 critical
Why it did not pass
- BOM not orderable: C1 (MPN 50ZLH100MEFC6.3X11 not in catalog snapshot 2026-10); C7,C8 (MPN GRM32ER71C226KE18L not in catalog snapshot 2026-10); D3 (LCSC C72043 not in catalog snapshot 2026-10); J1 (MPN KF301-5.08-2P not in catalog snapshot 2026-10); J2 (MPN KF301-5.08-2P not in catalog snapshot 2026-10)
esp32s3 devkit
Checks failedGPT-6.1 Sol · $1.03 · Oct 2, 2026
Gate L2· ERC: 0 critical· DRC: 0 critical
Why it did not pass
- BOM not orderable: J2 (LCSC C50949 not in catalog snapshot 2026-10); J3 (LCSC C50949 not in catalog snapshot 2026-10)
lipo charger usbc
Checks failedGPT-6.1 Sol · $0.76 · Oct 2, 2026
Gate L2· ERC: 0 critical· DRC: 0 critical
Why it did not pass
- BOM not orderable: D2 (LCSC C72043 not in catalog snapshot 2026-10)
stm32g031 mini
Incomplete / failedGPT-6.1 Sol · $0.00 · Oct 2, 2026
Gate L0
Download native KiCad board
buck 24v 5v 3a
Checks failedGPT-6 Astra · $5.17 · Oct 3, 2026
Gate L2· ERC: 0 critical· DRC: 0 critical
Why it did not pass
- BOM not orderable: C1 (MPN UPM1H101MPD not in catalog snapshot 2026-10); D3 (LCSC C72043 not in catalog snapshot 2026-10); J1 (MPN KF301-5.08-2P not in catalog snapshot 2026-10); J2 (MPN KF301-5.08-2P not in catalog snapshot 2026-10)
esp32 wroom breakout
Checks failedGPT-6 Astra · $9.85 · Oct 3, 2026
Gate L2· ERC: 0 critical· DRC: 0 critical
Why it did not pass
- BOM not orderable: C1,C2,C3 (footprint 0603 vs catalog package 0805); C4 (LCSC C14623 not in catalog snapshot 2026-10); R3,R4 (R3: LCSC C14663 is a mlcc, not a R part)
lipo charger usbc
Checks failedGPT-6 Astra · $3.74 · Oct 3, 2026
Gate L2· ERC: 0 critical· DRC: 0 critical
Why it did not pass
- BOM not orderable: D2 (footprint 0603 vs catalog package 0805)
stm32g031 mini
Incomplete / failedGPT-6 Astra · $0.00 · Oct 3, 2026
Gate L0
Download native KiCad board
bme280 breakout
Incomplete / failedGPT-6 Luna · $0.00 · Oct 4, 2026
Gate L0
Download native KiCad board
lipo charger usbc
Incomplete / failedGPT-6 Luna · $0.00 · Oct 4, 2026
Gate L0
Download native KiCad board
17 of 17 previews shown. Rendered from recorded native KiCad outputs. Missing 3D component models appear as pads. These are digital designs, not fabricated or bench-tested boards.
